Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit

SKU: KRHUB-1056-001
* When push the wheelchair, the controller will automatically detect the running state of the wheelchair and start the motor, pushing the wheelchair forward, to achieve the assistance effect.
* When the wheelchair backward sliding, the controller will automatically lock the motor, to prevent the wheelchair backward sliding.
* The JQB1-8 is lightweight and easy to install. It can be fit on essentially any make and type of wheelchair, including folding, tilt-in space, one-arm drive and standing.
0.0 (0 Reviews)
1 Sold
$1,580.00 $997.00
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • Type:
    For EU standard
    For EU standard
    For UK standard
    For UK standard
    For US standard
    For US standard
Quantity
-
+
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
1/1
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Kunray JQ-B2 24V 250W 8INCH Wheelchair Power Assisted Brushless Gear Motor Intelligent Conversion Kit
  • Description

Features:
✅ When push the wheelchair, the controller will automatically detect the running state of the wheelchair and start the motor, pushing the wheelchair forward, to achieve the assistance effect.
✅ When the need for wheelchair automatically forward, only the continuous application of the wheelchair thrust, wheelchair can be based on the actual situation before the uniform.
✅ When the wheelchair backward sliding, the controller will automatically lock the motor, the faster backward sliding speed, the greater lock force for motor, to prevent the wheelchair backward sliding.

✅ The JQB1-8 is lightweight and easy to install. It can be fit on essentially any make and type of wheelchair, including folding, tilt-in space, one-arm drive and standing.

Intelligent power assist system

1. Controller undervoltage: 21±0.5V

2. Controller rated voltage: 24v

3. Battery specification: 6.6Ah

4. Battery type: lithium battery

5. Charger input voltage: AC220V

6. Motor rated voltage: DC24V

7. Charger output current: DC2±0.2A

8. Motor running current: <3A

9. Drive system operating temperature: -20℃~+60℃

10. Motor speed: 2.5Km±1 Km or 8Km±1 Km(Max)

11. 8inch Rear Assistance intelligent system.

12. Waterproffing Grade: IP54

13. Material: Aluminum Alloy,

14. RPM:500R/min,

15. Range: 15-30km about


Wheel hub motors are steadily becoming not only electric bicycles but standard driving methods for electric wheelchairs, solar cars and many other light electric vehicles. With hub motor switching, no external mounting brackets and drive chains are required to support the motor and transmission. Make life easier.
